- Functional Description
- Specifications
- Applications
1、For PC communication directly with the DALI network.
2、With DALI USB interface module and configurationsoftware, lamp drivers or ballasts can be easily addressed and programmed.
型號/Type | JD-USB | ? | 執行標準/ Standard |
供(gong)電/Power Supply | By USB | ||
電流(liu)/ Current | 6mA | ? | IEC 62386-101(DALI協議標準(zhun)) |
輸入(ru)/ Input | USB（PC） | ? | IEC 62386-102(DALI協議標準) |
輸出/ Output | DALI | ? | EN ?60598-1(Glow-wire test) |
工作溫度/ Operating Temperature | 0～+50℃ | ? | IEC 60929(DALI V0) IEC 62386(DALI V1) |
? | ? | ? | ? |
?
-
