- Functional Description
- Specifications
- Applications
1、3 independent relay output controlled by DALI.
2、The maximum current load of each contact is 10A.
3、Each switch contact assigned with one DALI address輸入電壓范圍 /Input voltage range | 220～240VAC | ? | 執(zhi)行(xing)標準// Standard |
輸(shu)入(ru)頻率/ Input Frequency | 50/60Hz | ? | IEC 62386-101(DALI協議標準) |
功率/ Power | <2W（Max） | ? | IEC 62386-102(DALI協議標準) |
輸(shu)出繼電器觸點(dian)額(e)定電流 / Output relay contacts rated current | 10A | ? | ? |
環境溫度 / Ambient temperature | 0～50℃ | ? | ? |
儲(chu)存溫(wen)度 / Storage Temperature | -20～70℃ | ? | ? |
濕(shi)度/ Humidity | 5%～85% | ? | ? |
保(bao)護等級 / Protection class | IP20 | ? | ? |
-
